Description
Product Description
DETAILS
ALWAYS ON THE CUTTING EDGE.
Cutting edge performance starts with cutting edge LED technology. To achieve genuine category leading performance our Type-X™ Pro is equipped with 37 x Oslon High-Flux LEDs, selected for having the #1 highest lumen density per mm2 of any other comparable LED on the market. Compared to the two other leading spot lights brands similar offerings, the LEDs used in Type-X™ PRO have + 23% and +42% higher lumen density per mm2 in comparison. The net result is higher net light volume and unrivalled beam throw.
A WOLF IN WOLF’S CLOTHING
The hard-coated optical grade lens shares the same DNA as ballistic glass making it virtually indestructible. A UV stabiliser has also been added to ensure our lenses truly withstand the test of time with no discolouring or UV degradation. This has allowed us to do away with any secondary lens covers or filters which are known to significantly reduce light transmission.
ICONIC PERFORMANCE
Using the latest optic simulation modelling, the reflector geometry was tweaked over and over again to achieve a highly usable beam pattern. No doubt the attention grabber is the unrelenting beam distance of 1,155m (tested in pairs, combo beam), however the real strength of our Type-X™ PRO is in mid to long light distribution that really sets it apart.
Our key focus was on driver confidence, by increasing the beam throw the driver has longer analysis time. We maximised driver comfort by smoothing out the beam eliminating shadows. We reduced the light wasted in unimportant zones like treetops and immediately in front of the vehicle. The result is a homogeneous, unrelenting beam that that will support you well in any adventure. .
Unlike our competitors each Type-X™ PRO lamp has 6 built in flood reflectors for improved light distribution out into the road shoulders. The built in wide-beam reflector eliminates the need to add any wide beam covers, which are not only less efficient at distributing light, covers also withhold valuable light transmission.
SPECIFICATIONS
| LED | 37 x Oslon High-Flux LED |
| RAW LUMENS | 26,270 (Pair) |
| TESTED LUMENS | 15,870 (Pair) |
| AMP DRAW | 10.4A @ 13.2v (each) |
| POWER DRAW | 137W |
| CANDELA | 1,334,025cd |
| BEAM PATTERN | 6 x Spread 31 x Pencil Beam |
| INGRESS PROTECTION | IP68 | Submersible up to 3m |
| COLOUR TEMP (CCT) | 5700K |
| VOLTAGE COMPATIBILITY | 12v & 24v |
| LUMEN MAINTENANCE | 50,000 LM-80 |
| WEIGHT | 2.860kg (each) |
| PHOTOMETRIC DATA | |
| 10 M | 13,340 Lx |
| 50 M | 533 Lx |
| 200 M | 33 Lx |
| 300 M | 14 Lx |
| 400 M | 8 Lx |
| 1,000 M | 1.3 Lx |
| 1,155 M | 1 Lx |
THE PRO STANDARD
You only need one glance to realise that the sky was the limit when designing the STEDI TYPE-X ™ PRO (Registered Design Number 201814836 & Registered Trademark)
Back in 2016 we released the original Type-X™ and completely disrupted the high performance driving light market. If you haven’t heard about the legendary reputation of V1.0 TYPE-X™, start by checking out the Youtube comparisons. With the introduction of our PRO Edition we are yet again redefining the auxiliary driving light category. Our all new Type-X™ PRO edition epitomises our commitment to maximising light output and reliability at levels that surpass the most respected players in the industry.
1.15KM BEAM THROW
Using the latest optic simulation modelling, the reflector geometry was tweaked over and over again to achieve a highly functional beam pattern. No doubt the attention grabber is the unrelenting beam distance of 1.155km, however the real strength of our Type-X™ PRO is in mid to long range light distribution that really sets it apart. Astonishing beam throw coupled with a homogeneous wide beam will have you insist on driving only when the sun’s down.
